Coronary
X-treme XT-A/XT-R
Extreme Precision for Complex Lesions
穿通性とトルク力を追求
閉塞内でのActiveなワイヤーコントロールを求めるDr.へ。
Tip load 1.0gf guide wire.
Torque and control enhance crossability for the occluded lesions without a stump.
■Fielder XT-R
Tip load 0.6 gf guide wire.
Flexibility and control provide trackability for the channel tracking and sub total occlusion (99%).
■Trackability
Flexibility & control provide trackability
XT-R had better performance for the channel tracking
■Torque Response
It provides better control ability by fixing guide wire tip to the right direction.
■Small tip shapeability
It provides the potential for the loose tissue and collateral channel tracking by a small curve and tapered tip.
* All the data were obtained by company standardized test, which may differ from industry standardized tests.
* All the data do not prove that all devices have exactly the same performance with the samples used for these tests.
Technology
ACT ONE
This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.
ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.
-
-
Torque Force
Product Spec
| Tip Load | 1gf (XT-A), 0.6gf (XT-R) |
|---|---|
| Tip Shape | Straight |
| Radiopaque Length | 16cm |
| Coating | Polymer＋Hydrophilic |
| Usable Length | 190cm |
| Structure |
|
| Category |
