Coronary

ASAHI Gaia Next

Technology

ACT ONE

This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.

ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.

  • Torque Force
    Torque Force
Close

XTRAND Coil

This is a hollow coil which is formed by using more than one rope each made up of multiple strands.

The difference from a single coil is that extension in the longitudinal axis direction is small and the strength against tension is high. This coil was developed to avoid fracture and intravascular persistence of the wire even if the tip of the guidewire is caught in endovascular tissue. Also, the XTRAND coil is characterized by its high flexibility in the transverse axis direction, high torque response, and high torque force.

  • Coil extension
    Coil extension
  • Strength against tension
    Strength against tension
Close

Product Spec

Tip Shape Pre-shape
Radiopaque Length 15cm
Coating Hydrophilic
Usable Length 190cm / 300cm
Structure
Category

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coil Length Radiopaque Length Coating Coating Length
ASAHI Gaia Next 1 AH14R019P Pre-shape 190cm 0.27/0.36mm (0.011/0.014") 15cm 15cm Hydrophilic 400mm
ASAHI Gaia Next 2 AH14R020P Pre-shape 190cm 0.30/0.36mm (0.012/0.014") 15cm 15cm Hydrophilic 400mm
ASAHI Gaia Next 3 AH14R021P Pre-shape 190cm 0.30/0.36mm (0.012/0.014") 15cm 15cm Hydrophilic 400mm
ASAHI Gaia Next 1 AH14R319P Pre-shape 300cm 0.27/0.36mm (0.011/0.014") 15cm 15cm Hydrophilic 400mm
ASAHI Gaia Next 2 AH14R320P Pre-shape 300cm 0.30/0.36mm (0.012/0.014") 15cm 15cm Hydrophilic 400mm
ASAHI Gaia Next 3 AH14R321P Pre-shape 300cm 0.30/0.36mm (0.012/0.014") 15cm 15cm Hydrophilic 400mm

Not all models are available in all markets.
Please check availability with your sales representative.
