Coronary

ASAHI SION black

Polymer jacket frontline guide wire for complex cases.

Smooth trackability in your hand

■Lubricity
Polymer jacket characteristics allow smooth lesion entry and crossing

■Tip flexibility
Compared with conventional polymer jacket wires, ASAHI SION black is flexible laterally.
This increases vessel tracking capability in tortuous lesion.

■Durability
ASAHI SION black is hardly effected by the curve.
Tip durability by ACT ONE helps maintain operability through tortuous vessels.

■SION series positioning

* All the data were obtained by company standardized test, which may differ from industry standardized tests.
* All the data do not prove that all devices have exactly the same performance with the samples used for these tests.

Technology

ACT ONE

This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.

ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.

  • Torque Force
    Torque Force
Close

Product Spec

Tip Load 0.8gf
Tip Shape Straight / Pre-shape / J-shape
Radiopaque Length 3cm
Coating Polymer＋Hydrophilic
Usable Length 190cm / 300cm
Structure
Category
Product spec comparison

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coil Length Radiopaque Length Coating Coating Length
ASAHI SION black APW14R010J J 190cm 0.36mm (0.014") 12cm 3cm Polymer＋Hydrophilic 400mm
ASAHI SION black APW14R010P Pre-shape 190cm 0.36mm (0.014") 12cm 3cm Polymer＋Hydrophilic 400mm
ASAHI SION black APW14R010S Straight 190cm 0.36mm (0.014") 12cm 3cm Polymer＋Hydrophilic 400mm
ASAHI SION black APW14R310J J 300cm 0.36mm (0.014") 12cm 3cm Polymer＋Hydrophilic 400mm
ASAHI SION black APW14R310P Pre-shape 300cm 0.36mm (0.014") 12cm 3cm Polymer＋Hydrophilic 400mm
ASAHI SION black APW14R310S Straight 300cm 0.36mm (0.014") 12cm 3cm Polymer＋Hydrophilic 400mm

“ASAHI”, “SION" and "ACT ONE" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT® coating.

The tip load values of our guide wires are the values assuming the force that the tip of the guide wire pushes the lesion on the basis of company standardized test.
There are individual differences in values of actual devices.
