Coronary

ASAHI SION

Hydrophilic frontline guide wire with excellent trackability in tortuous vessels

Complete cases from start to finish with only one guide wire

■Composite core
Composite core improves torque and tip shape retention

・ACT ONE benefits
1. Shape protection
2. Torque transmission

・Twist core benefits
1. Stronger tip
2. Negates Whipping

■Tip flexibiity
ASAHI SION has good trackability allowing for deep distal placement

■SION series positioning

* All the data were obtained by company standardized test, which may differ from industry standardized tests.
* All the data do not prove that all devices have exactly the same performance with the samples used for these tests.

Technology

ACT ONE

This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.

ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.

  • Torque Force
    Torque Force
Close

Product Spec

Tip Load 0.7gf
Tip Shape Straight / J-shape
Radiopaque Length 3cm
Coating Hydrophilic
Usable Length 190cm / 300cm
Structure
Category
Product spec comparison

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coil Length Radiopaque Length Coating Coating Length
ASAHI SION AHW14R101S Straight 190cm 0.36mm (0.014") 28cm 3cm Hydrophilic 280mm
ASAHI SION AHW14R301S Straight 300cm 0.36mm (0.014") 28cm 3cm Hydrophilic 280mm
ASAHI SION AHW14R101J J 190cm 0.36mm (0.014") 28cm 3cm Hydrophilic 280mm
ASAHI SION AHW14R301J J 300cm 0.36mm (0.014") 28cm 3cm Hydrophilic 280mm

“ASAHI”, “SION" and "ACT ONE" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT® coating.

The tip load values of our guide wires are the values assuming the force that the tip of the guide wire pushes the lesion on the basis of company standardized test.
There are individual differences in values of actual devices.
