Coronary

Rinato/PROWATER

First choice guide wire with floppy tip and moderate core wire support.
Good maneuverability and support.
Silicone coating up to 30mm from the tip for floppy tip.

Product Spec

Tip Load 0.8gf
Tip Shape Straight / J-shape
Radiopaque Length 3cm
Coating Silicone＋Hydrophilic
Usable Length 180cm / 300cm
Structure
Category
Product spec comparison

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coil Length Radiopaque Length Coating
Rinato/PROWATER AGH146000 Straight 180cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic
Rinato/PROWATER AGH146000J J 180cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic
Rinato/PROWATER AGH146300 Straight 300cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic
Rinato/PROWATER AGH146300J J 300cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic

“Rinato” and “PROWATER" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT®coating.

The tip load values of our guide wires are the values assuming the force that the tip of the guide wire pushes the lesion on the basis of company standardized test.
There are individual differences in values of actual devices.
