Coronary

Route/PROWATERflex

First choice guide wire featuring a soft tip with good shaping memory and trackability
Silicone coating up to 30mm from the tip.

Product Spec

Tip Load 0.8gf
Tip Shape Straight / J-shape
Radiopaque Length 3cm
Coating Silicone＋Hydrophilic
Usable Length 180cm / 300cm
Structure
Category
Product spec comparison

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coil Length Radiopaque Length Coating
Route/PROWATERflex AGH147000 Straight 180cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic
Route/PROWATERflex AGH147000J J 180cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic
Route/PROWATERflex AGH147300 Straight 300cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic
Route/PROWATERflex AGH147300J J 300cm 0.36mm (0.014") 20cm 3cm Silicone＋Hydrophilic

“Route” and “PROWATERflex" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.

The tip load values of our guide wires are the values assuming the force that the tip of the guide wire pushes the lesion on the basis of company standardized test.
There are individual differences in values of actual devices.
