Neuro

ASAHI CHIKAI

ASAHI CHIKAI is 0.014inch work horse guide wire

Providing good torque response and support for neuro interventional procedures.

Technology

ACT ONE

This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.

ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.

  • Torque Force
    Torque Force
Close

Product Spec

Shaft Outer Diameter 0.36mm (0.014")
Tip Shape Straight / Round Curve
Usable Length 200cm / 300cm
Structure
Category

Order Information

Product Name Catalog No. Usable Length Outer Diameter Coil Length Radiopaque Length Tip Shape Hydrophilic Coating Length
ASAHI CHIKAI WAIN-CKI-200 200cm 0.36mm (0.014") 30cm 5cm Straight 170cm
ASAHI CHIKAI WAIN-CKI-200-RC 200cm 0.36mm (0.014") 30cm 5cm Round curve 170cm
ASAHI CHIKAI WAIN-CKI-300 300cm 0.36mm (0.014") 30cm 5cm Straight 170cm
ASAHI CHIKAI WAIN-CKI-300-RC 300cm 0.36mm (0.014") 30cm 5cm Round curve 170cm

“ASAHI”, "CHIKAI" and "ACT ONE" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT® coating.
