Peripheral
ASAHI Gaia PV
Deflection and directional control with balanced penetration force and torque response.
■Penetrability by "Micro-cone tip"
The ball tip was made smaller to increase its penetration efficacy.
The micro-cone tip makes it easier to make the entry route to the hard tissue and fibrous cap.
■Tip flexibility
By taking advantage of tip flexibility, ASAHI Gaia PV easily avoids hard tissue and advances smoothly.
Deflection control: Guiding the wire to the distal true lumen with rotational control by using deflection which occurs when advancing a shaped GW.
■1mm pre-shaped tip
The pre-shape of the tip is incorporated in the production process, significantly increase tip shape retention.
* All the data were obtained by company standardized test, which may differ from industry standardized tests.
* All the data do not prove that all devices have exactly the same performance with the samples used for these tests.
Technology
ACT ONE
This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.
ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.
-
-
Torque Force
Product Spec
| Tip Load | 7.5gf |
|---|---|
| Tip Shape | Pre-shape |
| Radiopaque Length | 15cm |
| Coating | Hydrophilic (Uncoated Ball Tip) |
| Usable Length | 200cm / 235cm / 300cm |
| Structure |
|
| Category |
