Peripheral

ASAHI Gladius 0.014

Enable to treat broad range of cases from simple stenosis to occluded lesions.

■Moderate tip load with good support
3.0gf tip load for 0.014 inch make possible to use for a broad range of cases from simple stenosis to occluded lesions as a soft wire.

■Tip durability
High level retention of core wire due to ACT ONE.
Used for occluded lesion and muliti-vessel.

■Mini-preshape
Tip pre-shaped in the manufacturing process with a 1mm curve.
Easier to shape than shape manually.

■Polymer jacket for lubricity
Quickly cross even calcified lesions and fibrous occlusions.

■Pushability
Easy push force transmission due to balanced support shaft design.
Suitable for tortuous vessel and cross over approach due to the smooth shaft design.

Technology

Product Spec

Tip Load 3gf
Tip Shape Pre-shape / Straight
Radiopaque Length 3cm
Coating Polymer+Hydrophilic
Usable Length 200cm / 235cm / 300cm
Structure
Category

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coating Coating Length Coil Length Radiopaque Length
Gladius 0.014 PPW14R100P Pre-shape 200cm 0.36mm (0.014") Polymer Jacket + Hydrophilic Coating 50cm 11cm 3cm
Gladius 0.014 PPW14R100S Straight 200cm 0.36mm (0.014") Polymer Jacket + Hydrophilic Coating 50cm 11cm 3cm
Gladius 0.014 PPW14R200P Pre-shape 235cm 0.36mm (0.014") Polymer Jacket + Hydrophilic Coating 50cm 11cm 3cm
Gladius 0.014 PPW14R200S Straight 235cm 0.36mm (0.014") Polymer Jacket + Hydrophilic Coating 50cm 11cm 3cm
Gladius 0.014 PPW14R300P Pre-shape 300cm 0.36mm (0.014") Polymer Jacket + Hydrophilic Coating 50cm 11cm 3cm
Gladius 0.014 PPW14R300S Straight 300cm 0.36mm (0.014") Polymer Jacket + Hydrophilic Coating 50cm 11cm 3cm

“Gladius" and "ACT ONE" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT® coating.

The tip load values of our guide wires are the values assuming the force that the tip of the guide wire pushes the lesion on the basis of company standardized test.
There are individual differences in values of actual devices.
