Peripheral
ASAHI Halberd 0.014
Stiff tip guidewire with precise torque control and penetration to cross resistant lesions
Micro-cone tip increases penetration efficacy for crossing CTO lesions
■Mini pre-shape-Better shape retention throughout the procedure
Tip pre-shaped in the manufacturing process with a 1mm curve-easier for the physician than shaping manually.
Able to efficiently reshape the curve to a more acute angle.
Able to change the shape depending on the lesion or procedural situation.
■micro-cone tip
The ball tip was made smaller to increase its penetration efficacy
■Armored tip
Soldered from the pre-shaped part until the ball tip
Easy directional control in calcified occluded lesions due to surperior tip shape retention.
Technology
ACT ONE
This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.
ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.
-
-
Torque Force
Product Spec
| Tip Load | 12gf |
|---|---|
| Tip Shape | Pre-shape |
| Radiopaque Length | 5cm |
| Coating | Hydrophilic (Uncoated Ball Tip)SLIP-COAT® |
| Usable Length | 200cm / 235cm / 300cm |
| Structure |
|
| Category |
