Interventional Radiology

ASAHI Meister S14

Lower profile for the new stage of selective procedure（Transarterial Ablation : TAA）

■ Guide Wire Tip
- ACT ONE reinforcement for torque response.
- Single wire rope coil construction on the distal portion for tip flexibility.

■ Advantages of single wire rope coil
- Enhance tip flexibility by reducing metal volume compared to single coil


Technology

ACT ONE

This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.

ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.

  • Torque Force
    Torque Force
Close

Product Spec

Shaft Outer Diameter 0.36mm (0.014")
Tip Shape Angled 45°
Polymer Jacket Length 130cm / 160cm / 175cm
Usable Length 135cm / 165cm / 180cm
Structure
Category

Order Information

Product Name Catalog No. Usable Length Coil Length Shaft (O.D) Radiopaque Length Polymer Jacket Length Hydrophilic Coating Length Tip Shape
ASAHI Meister S14 AMS-135-1445 135cm 12cm 0.36mm (0.014") 3cm 130cm 130cm Angled 45°
ASAHI Meister S14 AMS-165-1445 165cm 12cm 0.36mm (0.014") 3cm 160cm 160cm Angled 45°
ASAHI Meister S14 AMS-180-1445 180cm 12cm 0.36mm (0.014") 3cm 175cm 175cm Angled 45°

"ASAHI"、"ASAHI Meister"and "ACT ONE"are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT® coating.
