Coronary
ASAHI SION
Hydrophilic frontline guide wire with excellent trackability in tortuous vessels
Complete cases from start to finish with only one guide wire
■Composite core
Composite core improves torque and tip shape retention
・ACT ONE benefits
1. Shape protection
2. Torque transmission
・Twist core benefits
1. Stronger tip
2. Negates Whipping
■Tip flexibiity
ASAHI SION has good trackability allowing for deep distal placement
The above data was (All the data were) obtained by company standardized test, which may differ from industry standardized tests.
The above data (All the data) does not prove that all devices have exactly the same performance with the samples used for these tests.
Technology
ACT ONE
This is a multi-wire coil using our core technologies for wire drawing, wire forming, and torque.
ACT ONE optimizes the balance of torque force, torque response, durability, and rigidity in guidewires and microcatheters for high performance.
-
-
Torque Force
Product Spec
| Tip Load | 0.7gf |
|---|---|
| Tip Shape | Straight / J-shape |
| Radiopaque Length | 3cm |
| Coating | Hydrophilic |
| Usable Length | 180cm / 300cm |
| Structure |
|
| Category |
