Coronary

ASAHI Gaia Next

■ XTRAND Coil
While ASAHI Gaia Next enables flexibility for deflection control, its original anti- damage feature, increases durability when trapped.

- Lower risk of guide wire damage
It avoids guide wire breakage even incase of trapping.

- Increased anti trapping power
It improves maneuverability in order to avoid guide wire trapping.

■ Improved performance from ASAHI Gaia series
By using the XTRAND coil, ASAHI Gaia Next series shows higher torque force. This helps to enable more precise manipulation of the tip.

*All the data were obtained by company standardized test, which may differ from industry standardized tests.
*All the data do not prove that all devices have exactly the same performance with the samples used for these tests.

Product Spec

Tip Load 2gf / 4gf / 6gf
Tip Shape Pre-shape
Radiopaque Length 15cm
Coating Hydrophilic
Usable Length 190cm
Structure
Category

Order Information

Product Name Catalog No. Tip Shape Usable Length Outer Diameter Coil Length Radiopaque Length Coating Coating Length
ASAHI Gaia Next 1 AH14R019P Pre-shape 190cm 0.27/0.36mm (0.011/0.014") 15cm 15cm Hydrophilic 40cm
ASAHI Gaia Next 2 AH14R020P Pre-shape 190cm 0.30/0.36mm (0.012/0.014") 15cm 15cm Hydrophilic 40cm
ASAHI Gaia Next 3 AH14R021P Pre-shape 190cm 0.30/0.36mm (0.012/0.014") 15cm 15cm Hydrophilic 40cm

ASAHI Gaia Next", "ACT ONE" and “XTRAND" are trademarks or registered trademarks of ASAHI INTECC CO., LTD. in Japan and other countries.
Coated with SLIP-COAT® coating.

The tip load values of our guide wires are the values assuming the force that the tip of the guide wire pushes the lesion on the basis of company standardized test.
There are individual differences in values of actual devices.
